MIDI-MULT: 6-way TRS MIDI thru module (4HP)

AVAILABLE FROM OCTOBER 7th 2024

IMPORTANT: This module uses Type A MIDI TRS connections - this is used by the likes of Korg, Akai and others, and is the adopted standard for MIDI over TRS. If you are unsure which standard your gear supports you can find an incomplete list at https://minimidi.world/ - there are currently no plans to support Type B or TS connections, except as custom jobs.

A 6-way MIDI THRU module to allow you to control your MIDI gear from your modular setup (or vice versa); think of it as a buffered multiple, but for MIDI data.

Any data presented at the input is mirrored to each of the six outputs, and since this is a 'dumb' module there is no capability for fancy routing or filtering (I'll have other modules for that, eventually)

This module has a working voltage of 5V, so make sure that anything you plan to connect to the module is 5V tolerant (most gear is, but it's worth checking beforehand). Should you require a module that runs at 3.3V, contact me in the first instance and we can sort something out.

4HP wide - supplied with power cable.
